Show Hidden Edges as dashed lines in 3D Model and 2D Layout
- In 3D modeling:
- Select Display Options palette from Display pull-down menu or press F9 key.
- Click on Hidden Line rendering icon, select Show Hidden Edges option, click Render button.
- In 2D Layout:
- Create a Frame that contains a 2D view of your 3D model.
- Right click on Frame and choose Parameters.
- In Frame Parameters dialog click on Options button in Graphics section of dialog.
- Select Show Hidden Edges option.
- Click OK button to regenerate frame with hidden edges visible.
