Derive 2D sections using the Contours tool
- Create a 3D solid or surface object.
- Select Contours tool then click on object.
- Observe the contours are displayed and can be edited in result buffer as follows:
- Move and rotate the controller to change orientation of the contours.
- In Tool Options set interval to either Increment distance or # Of Increments.
- In Tool Options set Layout to either Leave At Elevation or On XY Plane.
- Note, this tool can be applied to multiple objects simultaneously.
