Create the base and capital of a column with Subdivision modeling

  • Updated
  • Create base using Rectangle tool with 3D Extrude option.
  • Use Offset Outline with Insert option ON.
  • Reshape the inner face up.
  • Use Offset Outline and Reshape again to complete base cage.
  • Use Subdivision tool on base cage.
  • While in SubD edit mode select bottom face and change Sharpness to 100%, then select top face and change Sharpness to 50%.
  • Create capital cage using same method for base.
  • Use Subdivision tool on capital cage.
  • While in SubD edit mode select top face and the four vertical edges then change Sharpness to 100%.
  • Add your desired texture and render!
